    Brown Solid Color PVDF Coating Aluminum Composite Panel ACP Exterior Wall Cladding PE Glossy Exterior Composite Cladding

    Ask Lasest Price
    Brand Name : Alushang
    Model Number : 1220*2440MM 4MM
    Certification : CE/SGS/ISO9001
    Price : negotiable
    Payment Terms : L/C,D/A,D/P,T/T
    Supply Ability : 30000 Meter square /day
    Delivery Time : 15-20days
    • Product Details
    • Company Profile

    Brown Solid Color PVDF Coating Aluminum Composite Panel ACP Exterior Wall Cladding PE Glossy Exterior Composite Cladding

    Exterior Wall Cladding Panel PVDF coated Scratch-resistant brown cloth pattern Aluminum Composite Panel 4MM 1.22*2.44m

    Brown Solid Color PVDF Coating Aluminum Composite Panel ACP Exterior Wall Cladding PE Glossy Exterior Composite Cladding


    PVDF Aluminum Composite Panel

    PVDF Aluminum Composite Panel, commonly referred to as ACP PVDF, is a lightweight, durable, and multi-functional building material. It is composed of two thin aluminum sheets bonded to a non-aluminum core, usually polyethylene or a mineral-filled substance, with the front aluminum sheet finished with a PVDF (polyvinylidene fluoride) resin coating.

    PVDF coating, or Polyvinylidene Fluoride coating, is a high-performance liquid resin-based coating applied to metal, especially for architectural use, to protect it from weathering and fading


    ACP PVDF Coating Panel Structure

    • Protection Film
    • PVDF Coating
    • Aluminium Skin
    • Adhesive Layer (Polyolefin)
    • Polyethylene Core (LDPE)
    • Adhesive Layer (Polyolefin)
    • Aluminium Skin
    • Service Coating (Anti-corrosive)






    Specifications And Sizes

    Specifications and Sizes
    Aluminum Skin Thickness:0.06mm-0.50mm
    Total Panel Thickness:2mm-6mm
    Width:

    1000mm, 1220mm (regular), 1250mm, 1300mm,

    1500mm, 1550mm, 1575mm, (maximum)

    Length:Up to 5800mm
    Standard Size:1220mm (width)×2440mm (length)
    Production Capability:100,000sqm / month
    Inner core( Normal non toxic polyethylene, one side unbroken polyethylene, two side unbroken polyethylene, virgin LDPE, ) B1 non-combustible mineral filled core,A2 non-combustible mineral filled core
    Non-standard sizes and special colors are available depending on customers' offers

    Main Related Products

    Our workshop

    Applications

    1.Constructional exterior curtain walls;

    2.Decorative renovation for store-added old buildings;

    3.Indoors decoration for interior walls, ceilings, bathrooms, kitchens and balconies;

    4.Gallaies,exhibition,saloons,stores,offices,banks,hotels,restaurants and apartments;

    5.Advertisement board, display platforms and signboards;

    6.Raw materials in industrial purpose;

    7.Materials used for vehicle and boat.


    Packaging:

    1. Individual Wrapping:
      • The panels are first individually wrapped with a protective film. This film prevents scratches and surface damage, safeguarding the smooth and glossy finish of the PVDF coating. It acts as a shield to maintain the panel's appearance and quality.
    2. Pallet Placement:
      • The wrapped panels are then placed onto wooden pallets. The pallets are carefully constructed of high-quality wood, providing a stable and durable base to support the weight of the panels. The panels are arranged neatly and tightly on the pallets to reduce movement during transit.

    Shipping:
    We offer various shipping options to suit our customers' needs:
    For international orders, we work with trusted shipping companies to ensure safe and timely delivery.
    We also offer expedited shipping for urgent orders.
    Our team carefully monitors the shipping process to ensure that our products arrive at their destination in perfect condition.
    For any questions or concerns about our packaging and shipping methods, please don't hesitate to contact us. We are committed to providing the best service to our customers.
